Aluminium Flagpole

NO.   Height (m) lower tube(mm) Upper tube (mm) Inner tube (mm) Top Dia (mm) Bottom Dia (mm) Base Plate (mm) Embedded Plate (mm) Bolt Size (mm) Mounting Hole Dia (mm)
UAP-165/8.0 8 / 165×3.5 /   85 165 270/240/17.5 300/240/5 4×M20×1000 ∅20
UAP-165/8.5 8.5
UAP-165/9.0 9
UAP-165/9.5 9.5
UAP-165/10.0 10
UAP-165/10.5 10.5
UAP-165/11.0 11
UAP-183/12.0 12 3 9.0+0.3 183×4.1 114×3.0 1500 183 310/260/25 320/260/5 6×M20×1000
UAP-183/13.0 13 4 127×3.0
UAP-183/14.0 14 5 127×3.0
UAP-183/15.0 15 6 127×3.0
UAP-183/16.0 16 7 140×3.0
UAP-183/17.0 17 8 140×3.0
UAP-210/18.0 18 8 10.0+0.3 210×5.0 140×3.0
UAP-210/19.0 19 9 152×3.0 210 340/290/25 350/290/5 6×M20×1200
UAP-210/20.0 20 10 152×3.0
