Bottom Diameter: φ127x1000 mm
Spigot Diameter: φ60/76mm
Materials: Aluminum 6063-T6
Wall Thickness: 3mm
Surface Finish: Satin Brushed, Anodizing, Powder Coating
Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
 |
| Height (m) | Bottom Dia (mm) | Middle Dimension (mm) |
Top Dimension (mm) |
Door Dimension (mm) |
Door Position (mm) |
Flange Dimension (mm) |
Bolt Circle (mm) |
Bolt Size | |
| GLP12776-30-BS-FG | 3 | φ127x1000 (H) | φ100x500 (H) | φ76x1500 (H) | 85x400 | 500 | 260x260 | 200 | 4xM12 |
| GLP12776-30-BS-FG | 4 | φ127x1000 (H) | φ100x800 (H) | φ76x2000 (H) | 85x400 | 500 | 260x260 | 200 | 4xM16 |
| GLP12776-30-BS-FG | 5 | φ127x1500 (H) | φ100x1000 (H) | φ76x2500 (H) | 85x400 | 500 | 260x260 | 200 | 4xM18 |
