Flange Mount
| Item No. | |
|
|
![]() |
![]() |
![]() |
|
![]() |
| Height (m) | Bottom Dia (mm) | Top Dia (mm) | Door Dimension (mm) | Door Position (mm) | Flange Dimension (mm) | Bolt Circle (mm) | Bolt Size | |
| SBP152A-25-BS-FG | 2.5 | 100 | 152 | 100x400 | 500 | 260x260 | 200 | 4xM16 |
| SBP152A-30-BS-FG | 3 | 100 | 152 | 100x400 | 500 | 260x260 | 200 | 4xM16 |
| SBP152A-40-BS-FG | 4 | 100 | 152 | 100x400 | 500 | 260x260 | 200 | 4xM16 |
