Bottom Diameter: φ150mm
Materials: Aluminum 6063-T6
Wall Thickness: 4.0mm
Surface Finish: Satin Brushed, Anodizing, Powder Coating
Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
| Height (m) | Bottom Dia (mm) | Top Dia (mm) | Door Dimension (mm) | Door Position (mm) | Flange Dimension (mm) | Bolt Circle (mm) | Bolt Size | |
| SDP150-25-BS-FG | 2.5 | 150 | 150 | 100x400 | 500 | 260x260 | 200 | 4xM16 |
| SDP150-30-BS-FG | 3 | 150 | 150 | 100x400 | 500 | 260x260 | 200 | 4xM16 |
| SDP150-35-BS-FG | 3.5 | 150 | 150 | 100x400 | 500 | 260x260 | 200 | 4xM16 |
