Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
| Height (m) | Bottom Dia (mm) | Top Dia (mm) | Door Dimension (mm) | Door Position (mm) | Flange Dimension (mm) | Bolt Circle (mm) | Bolt Size | |
| RLP14076A-50-BS-FG | 5 | 140 | 76 | 100x400 | 500 | 260x260 | 200 | 4xM18 |
| RLP15289A-60-BS-FG | 6 | 152 | 89 | 100x400 | 500 | 320x320 | 250 | 4xM20 |
| RLP16595A-70-BS-FG | 7 | 165 | 95 | 100x400 | 500 | 320x320 | 250 | 4xM20 |
| RLP16595A-80-BS-FG | 8 | 165 | 95 | 100x400 | 500 | 400x400 | 300 | 4xM24 |
| RLP178114A-100-BS-FG | 10 | 178 | 114 | 100x400 | 500 | 400x400 | 300 | 4xM24 |
| RLP203140A-120-BS-FG | 12 | 203 | 140 | 100x400 | 500 | 400x400 | 300 | 4xM24 |
