Bottom Diameter: φ114mm
Materials: Aluminum 6063-T6
Wall Thickness: 3mm
Surface Finish: Satin Brushed, Anodizing, Powder Coating
Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
| Height(m) | Bottom Dia(mm) | Door Position(mm) | Flange Dimension(mm) | Door Dimension(mm) | Top Dia(mm) | Bolt Circle(mm) | Bolt Size | |
| GAP4560-25-BS-FG | 2.5 | 114 | 60 | 85x400 | 500 | 260x260 | 200 | 4xM12 |
| GAP4560-30-BS-FG | 3 | 114 | 60 | 85x400 | 500 | 260x260 | 200 | 4xM12 |
| GAP4560-35-BS-FG | 3.5 | 114 | 60 | 85x400 | 500 | 260x260 | 200 | 4xM12 |
| GAP4560-35-BS-FG | 4 | 114 | 60 | 85x400 | 500 | 260x260 | 200 | 4xM12 |
