Bottom Diameter: φ140mm
Materials: Aluminum 6063-T6
Wall Thickness: 3mm
Surface Finish: Satin Brushed, Anodizing, Powder Coating
Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
| Height (m) | Bottom Dia (mm) | Top Dia (mm) | Door Dimension (mm) | Door Position (mm) | Flange Dimension (mm) | Bolt Circle (mm) | Bolt Size | |
| GBP14076-25-BS-FG | 2.5 | 140 | 76 | 85x400 | 500 | 260x260 | 200 | 4xM12 |
| GBP14076-30-BS-FG | 3 | 140 | 76 | 85x400 | 500 | 260x260 | 200 | 4xM12 |
| GBP14076-35-BS-FG | 3.5 | 140 | 76 | 85x400 | 500 | 260x260 | 200 | 4xM16 |
| GBP14076-40-BS-FG | 4 | 140 | 76 | 85x400 | 500 | 260x260 | 200 | 4xM16 |
