Bottom Diameter: φ127mm
Spigot Diameter: φ60/76mm
Materials: Aluminum 6063-T6
Wall Thickness: 3mm
Surface Finish: Satin Brushed, Anodizing, Powder Coating
Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
| Height (m) | Bottom Dia (mm) | Top Dia (mm) | Door Dimension (mm) | Door Position (mm) | Flange Dimension (mm) | Bolt Circle (mm) | Bolt Size | |
| GCP127127-25-BS-FG | 2.5 | 127 | 127 | 85x400 | 300 | 260x260 | 200 | 4xM12 |
| GCP127127-30-BS-FG | 3 | 127 | 127 | 85x400 | 300 | 260x260 | 200 | 4xM12 |
| GCP127127-35-BS-FG | 3.5 | 127 | 127 | 85x400 | 300 | 260x260 | 200 | 4xM16 |
| GCP127127-40-BS-FG | 4 | 127 | 127 | 85x400 | 300 | 260x260 | 200 | 4xM16 |
